catalog
1. instrucment与Attach API2. BTrace: VM Attach的两种方式3. Sun JVM Attach API
1. instrucment与Attach API
JDK5中增加了一个包java.lang.instrucment，能够对JVM底层组件进行访问。在JDK 5中，Instrument 要求在运行前利用命令行参数或者系统参数来设置代理类，在实际的运行之中，虚拟机在初始化之时(在绝大多数的 Java 类库被载入之前)，instrumentation的设置已经启动，并在虚拟机中设置了回调函数，检测特定类的加载情况，并完成实际工作
在Java5中，开发基于Instrucment的应用，需要以下几个步骤1. 编写premain函数2. jar文件打包3. 运行agent
但是在实际的很多的情况下，我们没有办法在虚拟机启动之时就为其设定代理，这样实际上限制了instrument的应用。而Java SE 6的新特性改变了这种情况，通过Java Tool API中的attach方式，我们可以很方便地在运行过程中动态地设置加载代理类，以达到instrumentation的目的
在JDK6中，针对这点做了改进，开发者可以在main开始执行以后，再开启自己的Instrucment程序Attach API不是Java的标准API，而是Sun公司提供的一套扩展API，用来向目标JVM"附着"(Attach)代理工具程序的。有了它，开发者可以方便的监控一个JVM，运行一个外加的代理程序，Sun JVM Attach API功能上非常简单，仅提供了如下几个功能1. 列出当前所有的JVM实例描述2. Attach到其中一个JVM上，建立通信管道3. 让目标JVM加载Agent
Relevant Link:
http://iamzhongyong.iteye.com/blog/1843558
2. BTrace: VM Attach的两种方式
BTrace的特点之一就是可以动态Attach到一个运行的JVM进程上，然后根据BTrace脚本来对目标JVM进行相应的操作
JVM的 Attach有两种方式1. 指定javaagent参数2. 运行时动态attach
0x1: 指定javaagent参数
这种方式的特点就是在目标JVM启动时，就确定好了要加载什么样的代理对象，例如
java -javaagent:xxxx.jar TestMain
TestMain.java
package test;public class TestMain { public static void main(String[] args) throws InterruptedException { System.out.println("Hello"); }} TestAgent.java
package test;import java.lang.instrument.Instrumentation;import java.io.*;public class TestMain { public static void agentmain(String args, Instrumentation inst) throws Exception { System.out.println("Args:" + args); } public static void premain(String args, Instrumentation inst) throws Exception { System.out.println("Pre Args:" + args); Class[] classes = inst.getAllLoadedClasses(); for (Class clazz : classes) { System.out.println(clazz.getName()); } } } TestAgent类比较简单，最终它会在目标类的Main方法执行之前，执行premain方法，其主要动作是将以及加载的类打印出来。 我们需要将这个类打包成jar文件，以便在目标JVM启动时候，以参数形式指定给它。打成jar的同时，设定MANIFEST.MF文件的内容。告知目标JVM该如何处理
Agent-Class: TestAgentPremain-Class: TestAgentCan-Redine-Classes: trueCan-Retransform-Classes: true
用jar命令将TestAgent打包
1. 编译TestAgentjavac TestAgent.java2. jar打包jar cvmf MANIFEST.MF xxx.jar TestAgent.class
启动TestMain，并设置javaagent参数
1. 编译TestMainjavac TestMain.java 2. 启动TestMainjava -javaagent:xxx.jar TestMain
0x2: 动态Attach，load指定Agent
这种方式与之前指定参数的不同在于，其可以在JVM已经运行的情况下，动态的附着上去，并可以动态加载agent
TestMain.javapublic class TestMain { public static void main(String[] args) throws InterruptedException { while(true) { Thread.sleep(10000); new Thread(new WaitThread()).start(); } } static class WaitThread implements Runnable { @Override public void run() { System.out.println("Hello"); } } } TestAgent.java
import java.lang.instrument.Instrumentation;import java.io.*;public class TestAgent{ public static void agentmain(String args, Instrumentation inst) throws Exception { System.out.println("Args:" + args); } public static void premain(String args, Instrumentation inst) throws Exception { System.out.println("Pre Args:" + args); Class[] classes = inst.getAllLoadedClasses(); for (Class clazz : classes) { System.out.println(clazz.getName()); } } } 动态加载agent的情况下，被调用的是agentmain方法, 其会在JVMload的时候，被调用
MANIFEST.MFAgent-Class: TestAgentPremain-Class: TestAgentCan-Redine-Classes: trueCan-Retransform-Classes: true
将类打包为jar包
1. 编译TestAgentjavac TestAgent.java2. jar打包jar cvmf MANIFEST.MF xxx.jar TestAgent.class
动态附着到对应的JVM需要使用到JDK的Attach API
Main.javaimport com.sun.tools.attach.VirtualMachine;public class Main { public static void main(String[] args) throws Exception { VirtualMachine vm = null; String agentjarpath = "C:/Users/zhenghan.zh/Desktop/新建文件夹/xxx.jar"; //agentjar路径 vm = VirtualMachine.attach("9730");//目标JVM的进程ID（PID） vm.loadAgent(agentjarpath, "This is Args to the Agent."); vm.detach(); } } 一旦运行这个Main方法， 其就会动态的附着到我们对应的JVM进程中，并为目标JVM加载我们指定的Agent，以达到我们想做的事情， 比如BTrace就为在附着到目标JVM后，开启一个ServerSocket，以便达到与目标进程通讯的目的
Relevant Link:
http://ivanzhangwb.github.io/btrace-vm-attach-api/
3. Sun JVM Attach API
Sun JVM Attach API是Sun JVM中的一套非标准的可以连接到JVM上的API，从JDK6开始引入，除了Solaris平台的Sun JVM支持远程的Attach，在其他平台都只允许Attach到本地的JVM上
0x1: 列出当前所有的JVM实例描述
package test;import java.util.List;import com.sun.tools.attach.VirtualMachine;import com.sun.tools.attach.VirtualMachineDescriptor;public class Test { public static void main(String[] args) { List list = VirtualMachine.list(); for (VirtualMachineDescriptor vmd : list) { System.out.println("pid:" + vmd.id() + ":" + vmd.displayName()); } }}//tools.jar needs to be added to the IDE's library path and the program's classpath. The tools.jar file is found in the JDK's lib directory.
0x2: Attach到特定进程的JVM上，并加载Agent
//Attach到JVM上VirtualMachine virtualmachine = VirtualMachine.attach(pid); //加载AgentString javaHome = virtualmachine.getSystemProperties().getProperty("java.home"); String agentPath = javaHome + File.separator + "jre" + File.separator + "lib" + File.separator + "management-agent.jar"); File file = new File(agentPath); if(!file.exists()) { agentPath = javaHome + File.separator + "lib" + File.separator + "management-agent.jar"; file = new File(agentPath); if(!file.exists()) throw new IOException("Management agent not found"); } } agentPath = file.getCanonicalPath(); try { virtualmachine.loadAgent(agentPath, "com.sun.management.jmxremote"); } catch(AgentLoadException e) { throw new IOException(e); } catch(AgentInitializationException agentinitializationexception) { throw new IOException(e); } Properties properties = virtualmachine.getAgentProperties(); address = (String)properties.get("com.sun.management.jmxremote.localConnectorAddress"); virtualmachine.detach(); 0x3: Attach API底层实现(windows)
\openjdk\jdk\src\windows\classes\sun\tools\attach\WindowsAttachProvider.java
public VirtualMachine attachVirtualMachine(String vmid) throws AttachNotSupportedException, IOException{ checkAttachPermission(); // AttachNotSupportedException will be thrown if the target VM can be determined // to be not attachable. testAttachable(vmid); return new WindowsVirtualMachine(this, vmid);} \openjdk\jdk\src\windows\classes\sun\tools\attach\WindowsVirtualMachine.java
WindowsVirtualMachine(AttachProvider provider, String id) throws AttachNotSupportedException, IOException{ //继承HotSpotVirtualMachine super(provider, id); int pid; try { pid = Integer.parseInt(id); } catch (NumberFormatException x) { throw new AttachNotSupportedException("Invalid process identifier"); } //先连接上目标JVM hProcess = openProcess(pid); // The target VM might be a pre-6.0 VM so we enqueue a "null" command // which minimally tests that the enqueue function exists in the target // VM. try { enqueue(hProcess, stub, null, null); } catch (IOException x) { throw new AttachNotSupportedException(x.getMessage()); }} WindowsVirtualMachine继承HotSpotVirtualMachine，先看看HotSpotVirtualMachine的loadAgent方法
\openjdk\jdk\src\share\classes\sun\tools\attach\HotSpotVirtualMachine.java/** Load JPLIS agent which will load the agent JAR file and invoke* the agentmain method.*/public void loadAgent(String agent, String options) throws AgentLoadException, AgentInitializationException, IOException{ String args = agent; if (options != null) { args = args + "=" + options; } try { loadAgentLibrary("instrument", args); } catch (AgentLoadException x) { throw new InternalError("instrument library is missing in target VM"); } catch (AgentInitializationException x) { /* * Translate interesting errors into the right exception and * message (FIXME: create a better interface to the instrument * implementation so this isn't necessary) */ int rc = x.returnValue(); switch (rc) { case JNI_ENOMEM: throw new AgentLoadException("Insuffient memory"); case ATTACH_ERROR_BADJAR: throw new AgentLoadException("Agent JAR not found or no Agent-Class attribute"); case ATTACH_ERROR_NOTONCP: throw new AgentLoadException("Unable to add JAR file to system class path"); case ATTACH_ERROR_STARTFAIL: throw new AgentInitializationException("Agent JAR loaded but agent failed to initialize"); default : throw new AgentLoadException("Failed to load agent - unknown reason: " + rc); } }} loadAgentLibrary("instrument", args);
/** Load agent library* If isAbsolute is true then the agent library is the absolute path* to the library and thus will not be expanded in the target VM.* if isAbsolute is false then the agent library is just a library* name and it will be expended in the target VM.*/private void loadAgentLibrary(String agentLibrary, boolean isAbsolute, String options) throws AgentLoadException, AgentInitializationException, IOException{ InputStream in = execute("load", agentLibrary, isAbsolute ? "true" : "false", options); try { int result = readInt(in); if (result != 0) { throw new AgentInitializationException("Agent_OnAttach failed", result); } } finally { in.close(); }} 可以看到，Java在Attach到目标进行后，调用execute让目标进行加载Agent类，我们继续分析execute的实现方式，可以看到，JVM进程间通信是JVM Attach API的核心，JVM自身就预留了执行来自Attach进程的指令接口
\openjdk\jdk\src\windows\classes\sun\tools\attach\WindowsVirtualMachine.javaInputStream execute(String cmd, Object ... args) throws AgentLoadException, IOException{ assert args.length <= 3; // includes null // create a pipe using a random name int r = (new Random()).nextInt(); String pipename = "\\\\.\\pipe\\javatool" + r; long hPipe = createPipe(pipename); // check if we are detached - in theory it's possible that detach is invoked // after this check but before we enqueue the command. if (hProcess == -1) { closePipe(hPipe); throw new IOException("Detached from target VM"); } try { // enqueue the command to the process enqueue(hProcess, stub, cmd, pipename, args); // wait for command to complete - process will connect with the // completion status connectPipe(hPipe); // create an input stream for the pipe PipedInputStream is = new PipedInputStream(hPipe); // read completion status int status = readInt(is); if (status != 0) { // special case the load command so that the right exception is thrown if (cmd.equals("load")) { throw new AgentLoadException("Failed to load agent library"); } else { throw new IOException("Command failed in target VM"); } } // return the input stream return is; } catch (IOException ioe) { closePipe(hPipe); throw ioe; }} JVM的execute方法中调用了大量native方法，并且从代码中可以看出，JVM Attach的进程间通信使用了管道进行通信
Relevant Link:
http://ayufox.iteye.com/blog/655761 http://docs.oracle.com/javase/7/docs/jdk/api/attach/spec/com/sun/tools/attach/VirtualMachine.htmlhttp://docs.oracle.com/javase/7/docs/jdk/api/attach/spec/index.html
